The MIMIC M-Series Buzzer + Flasher (SKU: MB+F) is an industrial audible and visual signalling device designed for electrical control panels, industrial machinery, automation systems, and equipment fault-warning applications. It combines a high-pitch audible alarm with a bright flashing light to provide clear audio-visual alerts for operating conditions that require attention.
The unit features separate buzzer and flasher circuits, allowing the audible alarm to be acknowledged or switched OFF using an external push button and an additional hold-on circuit while the flashing light continues to operate. The flashing function stops when the input supply to the unit is disconnected.
Designed with an ABS body, polycarbonate cap, and a standard 22.5 mm panel cutout, the MIMIC M-Series Buzzer + Flasher is suitable for installation in compatible industrial control panels. It is available in multiple AC and DC voltage variants to meet different industrial signalling requirements.
| Parameter | Specification |
|---|---|
| Brand | MIMIC |
| Product Name | MIMIC M-Series Buzzer + Flasher |
| SKU / Model | MB+F |
| Product Series | M-Series |
| Function | Audible and visual signalling |
| Sound Type | High-pitch audible alarm |
| Sound Level | 90–110 dB, as specified |
| Visual Indication | Flashing light |
| Circuit Configuration | Separate buzzer and flasher circuits |
| Audio Control | External push button with an additional hold-on circuit |
| Flashing Frequency | 1 second ON, 0.5 second OFF |
| Available DC Voltages | 12V, 24V, 48V, 110V, 220V DC |
| Available AC Voltages | 24V, 110V, 230V AC |
| Body Material | ABS |
| Cap Material | Polycarbonate |
| Dimensions | 105 mm length × 60 mm diameter, as specified |
| Panel Cutout | 22.5 mm |
| Mounting Type | Panel mount |
| Protection Rating | IP54 |
| Maximum Power Consumption | 5 W, as specified |
| Connections | 2 connections, as specified |
| Connection Wire Size | 2 × 2.5 mm², as specified |
The MIMIC M-Series Buzzer + Flasher provides audible and visual alerts through separate buzzer and flasher circuits.
When the unit receives its input supply, the buzzer provides an audible alarm and the flasher provides a visual warning. The audible alarm can be acknowledged or switched OFF using an external push button connected through an additional hold-on circuit. This allows the buzzer to be switched OFF while the flasher continues operating.
The flashing function stops when the input supply to the unit is disconnected.
Note: The external push button and hold-on circuit are used for audio control. They should not be interpreted as a built-in audio-accept push button.
The MIMIC M-Series Buzzer + Flasher is suitable for:
The MIMIC M-Series Buzzer + Flasher combines audible and visual signalling in a compact panel-mounted device. Its separate buzzer and flasher circuits allow the audible alarm to be switched OFF through an external push-button and hold-on circuit while the visual warning continues. With multiple voltage options, an ABS body, a polycarbonate cap, and IP54 protection, it is designed for compatible industrial signalling applications.
MIMIC M-Series Buzzer + Flasher — Compact, Powerful and Reliable.
